Water resistance particle boards

The hallmark of chipboard with increased water resistance is a characteristic green color.

Water-resistant chipboard is used for the production of furniture, which will be operated in high humidity conditions. This is mainly furniture for bathrooms and kitchens.

Furniture produced from V.DSP more resistant to moisture and does not lose its properties during use in wet environments. However, it should be noted that it is also exposed to swell, just to a lesser degree than conventional chipboard.

Production of "Ivatsevichdrev" - plate chipboard with increased water resistance meets the requirements of technical normative legal acts: GOST 10632-2007, GN 2.6.1.10-1-01-2001.

Parameter (according to GOST 10632-2007)	Unit	Thickness range										Test method
		8	10	12	16	18	22	25	28	32	38
Average density	kg/ m3	740	730	710	680	675	660	665	650	635	625	GOST 10634
Max. density deviation inside of board	%	+ - 10										GOST 10634
Max. deviation on thickness	mm	+ - 0,30										GOST 27680
Max. deviation on lenght and width	mm	+ - 5,0										GOST 27680
Deviation of edge perpendicularity, max.	mm/m	2										GOST 27680
Swelling 24 hours, max.	%	20										GOST 10634
Modulus of rupture in bending	MPa	14,0		13,0		1,5			10,0		8,5	GOST 10635
Modulus of elasticity	MPa	1800		1600		1500			1350		1200	GOST 10635
Tensile strength perpendicular to surface of board	MPa	0,40		0,35		0,30			0,25		0,20	GOST 10636
Specific resistance to the normal separation of top layer	MPa	0,8										GOST 23234
Bow	mm	1,2										GOST 24053
Formaldehyde emission	mg/100 g	≤ 4,0  (emission class E0.5)										GOST 27678
Moisture content	%	5-13										GOST 10634

Size and thickness, mm	Quantity of boards in pallet	Weight of pallets, brutto (kg)	Quantity of pallets / boards in truck	Volume, m3
2440×1830×8	76	1900	11/836	29,863
2440×1830×16	38	1900	11/418	29,863
2440×1830×18	38	2000	10/380	30,542
2440×1830×22	30	2000	10/300	29,470
2440×1830×25	25	1900	11/275	30,698
2750×1830×8	74	2000	10/720	29,792
2750×1830×10	58	2000	10/580	29,189
2750×1830×15	40	2000	10/400	30,195
2750×1830×16	37	2000	10/370	29,792
2750×1830×18	33	2000	10/330	28,893
2750×1830×22	27	2000	10/270	29,893
2750×1830×25	24	2000	10/240	30,195
2750×1830×28	21	2000	10/210	29,519
2750×1830×32	19	2000	10/190	30,598
2750×1830×38	20	2500	8/160	30,598
2800×2070×8	65	2000	10/650	30,139
2800×2070×10	52	2000	10/520	30,603
2800×2070×12	44	2000	10/440	29,139
2800×2070×15	36	2000	10/360	30,429
2800×2070×16	34	2000	10/340	31,530
2800×2070×18	30	2000	10/300	21,298
2800×2070×22	24	2000	10/240	30,603
2800×2070×25	21	2000	10/210	30,429
2800×2070×28	18	2000	10/180	29,212
2800×2070×32	16	2000	10/160	29,676
2800×2070×38	14	2000	10/140	30,835
3050×1830×25	27	2500	8/216	30,140
3050×1830×28	21	2200	9/189	29,532
3050×1830×28	18	2500	8/144	30,542
3600×1830×38	15	2500	8/120	30,041
3600×2150×12	32	2000	10/320	30,217
3660×1830×16	35	2500	8/280	30,006
3660×1830×38	15	2500	8/120	30,542
